| TURBINE
BLOWERS / EXHAUSTERS |
|
PRINCIPLE
OF OPERATION : These blowers consists of a dynamically balanced impeller which revolves in a stator-cum-compression chamber having very fine clearances between them. The impeller is fitted directly on to the motor shaft. Both the suction and pressure openings are located on the outer periphery of the stator to reduce impedence to the air flow thereby developing vacuum and pressure. Since the impeller rotates with no contact between itself and the casing, there is no wear and tear and requires no lubrication APPLICATIONS : Manufacturing of textiles, Measuring, medical and laboratory equipment, Printing and paper handling, Vacuum packaging, Waste water treatment, Reprographics Industry, Aeration of fluids, Pneumatic Conveying, Plastic Industry, Industrial Ovens, Vacuum cleaners, Air Pollution monitoring equipment. FEATURES : • No lubrication is required since there is no friction and hence the air is absolutely oil free. • Practically nil maintenance cost. • Extremely compact units and can be mounted inside the machines • Silencer ensures low noise level.
|
| Model |
Capacity M3/Hr |
Pressure Mbar |
Vacuum Mbar |
Motor HP/KW |
Weight Kg |
| VR-50-2/1 | 80 | 85 | 75 | 0.5/0.37 | 16 |
| VR-75-2/1 | 150 | 120 | 100 | 0.75/0.56 | 26 |
| VR-100-2/1 | 200 | 140 | 125 | 1.0/0.74 | 26 |
| VR-125-2/1 | 280 | 170 | 145 | 2.0/1.50 | 40 |
| VR-150-2/1 | 400 | 200 | 180 | 3.0/2.20 | 45 |
| VR-175-2/1 | 500 | 240 | 210 | 5/3.50 | 58 |
| VR-200-2/1 | 600 | 260 | 240 | 7.5/5.57 | 70 |
| VR-250-2/1 | 800 | 340 | 300 | 10/7.50 | 10 |
| VR-300-2/1 | 1100 | 400 | 350 | 15/11.25 | 130 |
| Model |
Capacity M3/Hr |
Pressure Mbar |
Vacuum Mbar |
Motor HP/KW |
Weight Kg |
| VR-50-2/2 | 40 | 140 | 120 | 0.5/0.37 | 16 |
| VR-75-2/2 | 80 | 180 | 160 | 0.75/0.56 | 26 |
| VR-100-2/2 | 100 | 225 | 200 | 1.0/0.74 | 26 |
| VR-125-2/2 | 140 | 270 | 240 | 2.0/1.50 | 40 |
| VR-150-2/2 | 200 | 330 | 300 | 3.0/2.20 | 45 |
| VR-175-2/2 | 250 | 390 | 360 | 5/3.50 | 58 |
| VR-200-2/2 | 300 | 450 | 410 | 7.5/5.57 | 70 |
| VR-250-2/2 | 400 | 526 | 460 | 10/7.50 | 10 |
| VR-300-2/2 | 500 | 550 | 500 | 15/11.25 | 130 |
